Electrical Specification

Frequency Range

2400-2500MHz



VSWR

≤1.5



Input Impedance

50Ω



Gain

14dBi



Polarization Type

Vertical or Horizontal



Hoizontal PlaneΘHP

30±2°



Vertical PlaneΘHP

30±2°



Beam Electrical Down tilt



Front to Back Ratio

≥25dB



Maximum Input Power

50W



Connector Type

N -Female



Lightning Protection

DC ground

Mechanical Specifications



Dimension

190mm×190mm×30mm



Weight

0.5Kg



Rated Wind Velocity

210km/h



Radome material

UV-protected ABS



Diameter of Mounting pole

φ30-φ54mm



Working Temperature

-40~+60℃
