Electrical Specification

  Frequency Range

2400-2500MHz



VSWR

≤1.5



Input Impedance

50Ω



Gain

17dBi



Polarization Type

Vertical or Horizontal



Hoizontal PlaneΘHP

20±2°



Vertical PlaneΘHP

20±2°



Front to Back Ratio

≥26dB



Maximum Input Power

6W



Connector Type

N -Female



Lightning Protection

DC ground

Mechanical Specifications



Dimension

305mm * 305mm * 25mm



Weight

1.5Kg



Rated Wind Velocity

210km/h



Radome material

UV-protected ABS



Working Temperature

-40~+60℃
