•  Introduction

Empress™ 2.4GHz Active Reader Evaluation Kit (WIFI version)

Details:
1 x Empress™ Active Stationary Reader (HKRAR-EMWF)
20 x Hussar™ Slim Active Tag (HKRAT-NT02), with key chain
10 x Garrison™ Rugged Active Tag (HKRAT-RT02)
5 x Garrison™ Responsive Active Tag (HKRAT-ZT02)
1 x Software Development Kit

Other Tag Accessories:
3 x Silicone Case for Hussar™ Slim Tag
3 x Badge for Hussar™ Slim Tag

COMING SOON......

Electrical Specification

  Frequency Range

2400-2500MHz



VSWR

≤1.5



Input Impedance

50Ω



Gain

14dBi



Polarization Type

Vertical or Horizontal



Hoizontal Plane ΘHP

30±2°



Vertical Plane ΘHP

30±2°



Beam Electrical Down tilt



Front to Back Ratio

≥25dB



Maximum Input Power

50W



Connector Type

N -Female



Lightning Protection

DC ground

Mechanical Specifications



Dimension

190mm×190mm×30mm



Weight

0.5Kg



Rated Wind Velocity

210km/h



Radome material

UV-protected ABS



Diameter of Mounting pole

φ30-φ54mm



Working Temperature

-40~+60℃

COMING SOON......
